Test rychlosti – SSD SK Hynix BC501 256GB M.2

By | 10/01/2020

Last Updated on 10/10/2020 by administrator

Test rychlosti – SSD SK Hynix BC501 256GB M.2

SSD SK Hynix BC501 256GB M.2

Parametry:

Description: SSD SK Hynix BC501 256GB M.2
Model/Part Number: HFM256GDJTNG-8310A
Manufacturer: SK Hynix Inc. (South Korea)
Memory Size: 256 GB
Sequential Read/Write: 1600/780 MB/s
Interface: PCIe Gen3 x4 (4 x 985 MB/s), NVMe v1.2
Size / Dimension: 80.00mm x 22.00mm x 2.38mm
Memory Type: Flash NAND TLC
Operating Temperature: přesná hodnota nenalezena (obecně je to 0°C ~ 70°C)
Active Read/Write: 2,5W/2,5W
Idle: 40mW
Voltage – Supply: 3.3V

Zdroj:

https://www.skhynix.com/products.do?ct1=50&ct2=52&lang=eng
https://en.wikipedia.org/wiki/PCI_Express
https://support.hp.com/au-en/document/c06193977

Testovací sestava:

Notebook: HP 250 G7 6BP25EA

MB: Intel Cannon Lake-U PCH-LP Premium
CPU: Intel Core i5-8265U @ 1,6GHz
RAM: Micron 1 x 8 GB DDR4-2400 SDRAM
GPU: Intel UHD Graphics 620
OS: Windows 10 Pro 64bit, Version 1809 (OS Build 17763.914)

Aktuální parametry SSD na testovací sestavě:

CrystalDiskInfo:

----------------------------------------------------------------------------
CrystalDiskInfo 7.6.0 (C) 2008-2018 hiyohiyo
Crystal Dew World : https://crystalmark.info/
----------------------------------------------------------------------------
----------------------------------------------------------------------------
(1) SK hynix BC501 HFM256GDJTNG-8310A
----------------------------------------------------------------------------
Model : SK hynix BC501 HFM256GDJTNG-8310A
Firmware : 80002C00
Serial Number : NN91N594012201J33
Disk Size : 256,0 GB
Buffer Size : Neznámy údaj
# of Sectors :
Rotation Rate : ---- (SSD)
Interface : NVM Express
Major Version : NVM Express 1.2
Minor Version :
Transfer Mode : PCIe 3.0 x2 | PCIe 3.0 x2
Power On Hours : 86 hod.
Power On Count : 743 krát
Host Reads : 1042 GB
Host Writes : 1073 GB
Temperature : 36 C (96 F)
Health Status : Dobrý (100 %)
Features : S.M.A.R.T.
APM Level : ----
AAM Level : ----
Drive Letter : C:

SSD SK Hynix BC501 256GB M.2

Testování rychlosti:

CrystalDiskMark:

Profile: Default
Test: 1 GiB (x5) [Interval: 5 sec] <DefaultAffinity=DISABLED>

------------------------------------------------------------------------------
CrystalDiskMark 7.0.0 x64 (C) 2007-2019 hiyohiyo
Crystal Dew World: https://crystalmark.info/
------------------------------------------------------------------------------
* MB/s = 1,000,000 bytes/s [SATA/600 = 600,000,000 bytes/s]
* KB = 1000 bytes, KiB = 1024 bytes

[Read]
Sequential 1MiB (Q= 8, T= 1): 1687.020 MB/s [ 1608.9 IOPS] < 4968.52 us>
Sequential 1MiB (Q= 1, T= 1): 1040.335 MB/s [ 992.1 IOPS] < 1006.37 us>
Random 4KiB (Q= 32, T=16): 517.457 MB/s [ 126332.3 IOPS] < 4038.06 us>
Random 4KiB (Q= 1, T= 1): 44.833 MB/s [ 10945.6 IOPS] < 91.16 us>

[Write]
Sequential 1MiB (Q= 8, T= 1): 748.673 MB/s [ 714.0 IOPS] < 11165.01 us>
Sequential 1MiB (Q= 1, T= 1): 581.806 MB/s [ 554.9 IOPS] < 1795.09 us>
Random 4KiB (Q= 32, T=16): 381.642 MB/s [ 93174.3 IOPS] < 5483.94 us>
Random 4KiB (Q= 1, T= 1): 148.814 MB/s [ 36331.5 IOPS] < 27.34 us>

Test rychlosti - SSD SK Hynix BC501 256GB M.2 Test rychlosti - SSD SK Hynix BC501 256GB M.2

Test rychlosti - SSD SK Hynix BC501 256GB M.2

Profile: Default
Test: 1 GiB (x5) <0Fill> [Interval: 5 sec] <DefaultAffinity=DISABLED>

------------------------------------------------------------------------------
CrystalDiskMark 7.0.0 x64 (C) 2007-2019 hiyohiyo
Crystal Dew World: https://crystalmark.info/
------------------------------------------------------------------------------
* MB/s = 1,000,000 bytes/s [SATA/600 = 600,000,000 bytes/s]
* KB = 1000 bytes, KiB = 1024 bytes

[Read]
Sequential 1MiB (Q= 8, T= 1): 1770.195 MB/s [ 1688.2 IOPS] < 4734.76 us>
Sequential 1MiB (Q= 1, T= 1): 1005.330 MB/s [ 958.8 IOPS] < 1040.07 us>
Random 4KiB (Q= 32, T=16): 517.692 MB/s [ 126389.6 IOPS] < 4024.20 us>
Random 4KiB (Q= 1, T= 1): 44.726 MB/s [ 10919.4 IOPS] < 91.37 us>

[Write]
Sequential 1MiB (Q= 8, T= 1): 811.518 MB/s [ 773.9 IOPS] < 10296.52 us>
Sequential 1MiB (Q= 1, T= 1): 643.411 MB/s [ 613.6 IOPS] < 1623.74 us>
Random 4KiB (Q= 32, T=16): 437.814 MB/s [ 106888.2 IOPS] < 4780.82 us>
Random 4KiB (Q= 1, T= 1): 148.362 MB/s [ 36221.2 IOPS] < 27.41 us>

Test rychlosti - SSD SK Hynix BC501 256GB M.2 Test rychlosti - SSD SK Hynix BC501 256GB M.2

Test rychlosti - SSD SK Hynix BC501 256GB M.2

AS SDD Benchmark:

AS SSD Benchmark 2.0.6821.41776
------------------------------
Name: SK hynix BC501 HFM256GDJTNG-8310A
Firmware: 80002C00
Controller: stornvme
Offset: 283648 K - OK
Size: 238,47 GB
Date: 07.01.2020 22:00:22
------------------------------
16MB
------------------------------
Read: 96,30 iops
Write: 40,22 iops
------------------------------
4K:
------------------------------
Read: 10708 iops
Write: 32718 iops
------------------------------
4K-64Threads:
------------------------------
Read: 126033 iops
Write: 67082 iops
------------------------------
512B
------------------------------
Read: 16684 iops
Write: 28397 iops
------------------------------
Score:
------------------------------
Read: 688
Write: 454
Total: 1463
------------------------------

HFM256GDJTNG-8310A

HFM256GDJTNG-8310A

AS SDD Copy-Benchmark:

AS SSD Copy-Benchmark 2.0.6821.41776
------------------------------
Name: SK hynix BC501 HFM256GDJTNG-8310A
Firmware: 80002C00
Interface: stornvme
Size: 238,47 GB
Date: 07.01.2020 22:02:26
------------------------------
ISO
------------------------------
Speed:858,65 MB/s
Duration:1,25 s
------------------------------
Prog
------------------------------
Speed:271,84 MB/s
Duration:5,18 s
------------------------------
Game
------------------------------
Speed:306,81 MB/s
Duration:4,50 s

HFM256GDJTNG-8310A

AS SDD Compression Benchmark:

SSD SK Hynix BC501 256GB M.2

HD Tune:

HD Tune: NVMe SK hynix BC501 H Benchmark

Transfer Rate Minimum : 97.4 MB/sec
Transfer Rate Maximum : 959.9 MB/sec
Transfer Rate Average : 594.4 MB/sec
Access Time : 0.1 ms
Burst Rate : 204.5 MB/sec
CPU Usage : 1.8%

SSD SK Hynix BC501 256GB M.2

2 thoughts on “Test rychlosti – SSD SK Hynix BC501 256GB M.2

  1. Jitka Kučerová

    Dobrý den,
    mohl byste mě navigovat, jak zjistím použitou technologii v SSD disku (TLC nebo QLC ? ), výrobce to neuvádí.
    mám disk256Gb SK Hynix, HFB1A8MQ431A; 0MR; 031Y model BC511 (M.2 2280 S3); HFM256GDJTNI – 82A0A BA
    odkaz na OEM výrobce https://www.skhynix.com/products.do?ct1=50&ct2=52&lang=eng
    na webu HP (https://support.hp.com/au-en/product/hp-probook-450-g7-notebook-pc/29090065/document/c06475016) jsou 2 údaje k 256GB:
    256 GB PCIe NVMe M.2 Value SSD
    256 GB Intel PCIe NVMe QLC M.2 SSD with 16 GB Intel Optane memory H10
    Neumím ověřit, který použili, a v případě, že je v ntb disk označený jako “value SSD”, tak jestli je to také QLC
    děkuji

    Reply
    1. administrator Post author

      Zdravim Jitko,

      ano je to tak, vyrobce SK Hynix neuvadi tento parametr. Neco pres pul hodiny jsem googlil zda je mozne typ pameti najit pro Vas disk dokonce i na ruskych strankach, ale bez uspechu. Snad jedina moznost je budto napsat primo na jejich support, nebo sundat zadni cast notebooku a mrknout se zda na cipech neuvidite naspsano “Intel OPTANE” ci “3D NAND QLC/TLC” a to muze vypada nejak takto – https://www.intel.com/content/dam/products/hero/foreground/a1024664-ssd-optane-H10-storage-beauty-angle-2-16×9.png.rendition.intel.web.576.324.png

      Reply
